ECI-100 Universal Engine & Control InterfaceThe ECI-100 Universal Engine and Control Interface is an innovative and affordable solution for bridging engine instrumentation and drive-by-wire steering with Raymarine autopilot and navigation systems. A simple isolated CAN Bus solution, the ECI-100 offers reliable integration with Raymarine's latest generation of multifunction displays and also delivers a seamless autopilot steering interface to Raymarine's Evolution EV-2 Drive By Wire autopilot system.
Benefits:
A simple, single point of connection for engine data and drive-by-wire autopilot control
Affordable and uncomplicated solution eliminates the need for multiple engine and autopilot gateways
Brings Raymarine's Evolution 9-axis sensor and adaptive autopilot control to drive-by-wire propulsion without the need for a proprietary autopilot gateway
View engine data displays and enjoy full autopilot control alongside Raymarine's industry-leading radar, sonar and navigation technologies using a single touch screen display.
From our space saving aSeries, to our flagship big screen gS Series, engine information displays and autopilot control are available on any display running LightHouse v8 or later
Access easy to customize displays to show engine performance data, fuel consumption, alarms, and much more
View engine information displays on your smart phone or tablet with Raymarine mobile apps
Simple to install ECI-100 makes engine and navigation integration a reality for virtually any size vessel
Specifications
The specified price is for: 1 itemECI-100 Engine Data Parameters
The ECI-100 Universal Engine and Control Interface identifies the following parameters:
Engine speed
Engine oil temperature
Engine temperature
Engine oil pressure
Engine coolant pressure
Engine fuel rate
Boost pressure
Battery potential
Transmission oil pressure
Transmission oil temperature
Total engine hours
Fuel tank level
Trip fuel used (calculated by ECI-100)
Alternator potential
Engine torque
Engine percent load
Transmission gear
VIN (not shown on the display)
Software number (not shown on the display)
Simple Integration, Powerful Performance
The ultra-compact ECI-100 connects directly to the industry-standard NMEA2000 or SAE* J1939 Engine Data Bus used by major marine engine manufacturers including:
Volvo Penta
Yamaha Marine (Command Link Plus only)
Caterpillar
Yanmar Marine
Item number: E70227
UPC: 723193785263
Package weight: 0.6 lb
