FURUNO NavNet WAAS/GPS Antenna w/ NMEA0183
Cables
Marine Networking
Also available
Contents of the package
Features
Furuno's BBWGPS WAAS/GPS Receiver Antenna makes any NavNet product capable of receiving WAAS and GPS information. Now there is no need to have a separate unit to get your WAAS/GPS fix. This WAAS/GPS Receiver Antenna has everything you need built-in, and it delivers accuracy better then 3 meters by decoding GPS correction signals from the WAAS (Wide Area Augmentation System).In addition to its WAAS capability, the antenna has a compact 12-channel GPS Receiver that provides accurate and reliable position fixing. Simply connect the antenna to any NavNet display and you can display WAAS/GPS information on one display or the entire NavNet network.
WAAS (Wide Area Augmentation System) Receiver
12 Channel, All-in-View Parallel Tracking GPS Receiver
Up to 900 Knot Tracking Velocity
90 Second Cold Start Acquisition, 20 Second Warm State Acquisition
3M Accuracy or higher (95% of the time, SA off)
WAAS On/Off Selectable *
Power Requirements
12 VDC at 100 mA
Notes
*For more information on WAAS, please check the USCG Navigational Center web site:
www.navcen.uscg.gov
Specifications
Item number: BBWGPS
UPC: 611679267894
Package weight: 3 lb
