BRUNTON Compass F-5011-OR Quad 0-90 Orange
Contents of the package
- Compass
- Leather Case
- Lifetime Limited Warranty
Features
• Unique dual axis hollow hinge allows for easy and intuitive measurements of any line or plane.• The lid rotates 360˚ around both axes, making measurements possible for any surface including overhangs. The lid can extend or create the measurement surface itself.
• The default orientation of compass North makes this the only transit in the world that can measure strike & dip simultaneously. A simple rotation of the azimuth ring also allows simultaneous measurement of dip angle & dip direction if that is preferred.
• A secondary axis of rotation and lid protractor allows simultaneous measurement of trend & plunge.
• The hollow hinge/sighting tube allows for direct horizontal and vertical sighting measurements.
• Hinge dial enables dip angle measurements and also serves as a versatile protractor.
• Excellent contact and sighting measurement capabilities.
• Dual long-level bubbles allow the user to level the compass from the sides and bottom.
• The flat bottom allows for easier dip angle and dip azimuth measurements at low angles.
• The needle can be set to lock automatically, allowing for accurate readings.
• The precision NdFeB disc magnet provides very accurate readings and resists demagnetization.
• Our magnetic needle can be balanced for use almost anywhere in the world .
• Induction dampening makes for a quick-settling needle.
• A sapphire jewel bearing allows for smooth needle movement throughout the life of the instrument.
• The needle lock button can lock or free the needle, depending on the model.
• The internal components are sealed with an O-ring for improved water and dust resistance.
• All transits are compatible with our Jacob’s Staff/Tripod ball and socket adaptor.
• Each model is available in either Azimuth (0-360) or Quadrant (0-90) formats.
• Each comes with a protective leather case, perfect for carrying your Brunton in the field.
• Made in the USA in Riverton, Wyoming.
Specifications
• MEASUREMENT STYLE: unique, simultaneous methods• DIMENSIONS: 3.9 x 2.8 x 1.2 in | 10 x 7 x 3 cm
• WEIGHT: 12.1 oz | 341.6 g
• AZIMUTH: 1˚ graduations w/ ± 0.5˚ accuracy
• HINGE DIAL: 2˚ graduations w/ ± 1˚ accuracy
• PLUMB CLINOMETER: 1˚ graduations w/ ± 0.5˚ accuracy
• LID PROTRACTOR: 1˚ graduations w/ ± 0.5˚ accuracy
• DECLINATION ADJUSTMENT: ± 180˚
Item number: F-5011-OR
UPC: -
Package weight: 1 lb
