BRUNTON F-6060 Tactical Transit Compass Azimuth 0-360


Item: F-6060
This item is brand new
$434.95
Request price match
Extended Wty:none 1 yr.$43.50 2 yr.$65.24

Qty:

This item ships within 5 days
br
Ask a question   Tell a friend


Description

Contents of the package

  • Compass
  • protective weather-resistant case



Features

  • Made in the USA in Riverton, Wyoming.
  • Traditional transit measurement method.
  • The composite body is ultralight and tough.
  • The mirror enables sighting and measurement of bearings and vertical angles.
  • Short and long sights give the user additional functionality and accuracy when shooting bearings.
  • The precision NdFeB disc magnet provides very accurate readings and resists demagnetization.
  • Our magnetic needle can be balanced for use almost anywhere in the world.
  • Induction dampening makes for a quick-settling needle.
  • The sapphire jewel bearing allows for smooth needle movement throughout the life of the instrument.
  • The needle lock button can lock or free the needle, depending on the model.
  • The internal components are sealed with an O-ring for improved water and dust resistance.
  • All transits are compatible with our Jacob’s Staff/Tripod ball and socket adaptor.
  • Each model is available in either Azimuth (0-360) or MILS (0-6400) formats.
  • Each comes with a protective weather-resistant case with built-in belt loop and optional webbing clip.



    • Specifications

  • MEASUREMENT STYLE: Strike & Dip
  • DIMENSIONS: 3.1 x 2.7 x 1.4 in | 8.0 x 7.0 x 3.4 cm
  • WEIGHT: 5.8 oz | 165 g
  • AZIMUTH: 1˚ graduations w/ ± 0.5˚ accuracy
  • INTERNAL CLINOMETER: 1˚ graduations w/ ± 0.5˚ accuracy
  • PERCENT GRADE: 5% graduations
  • DECLINATION ADJUSTMENT: ± 180˚


    • Item number: F-6060
    UPC: 080078606007
    Package weight: 1 lb
